Success Hackintosh macOS Mojave 10.14.5 Build 18F132 at Gigabyte Z390 Aorus Xtreme + Intel Core i7-8700 + Sapphire Radeon VII 16GB
Specifications :
- Motherboard : Gigabyte Z390 Aorus Xtreme
- Processor : Intel Core i7-8700
- iGPU : Intel UHD 630
- eGPU : Sapphire Radeon VII 1G6B
- RAM : 64GB DDR4 PC17000/2133Mhz
- CPU Cooler : Cooler Master 360 RGB
- Storage : 1x WDC NVME 1TB + 1x Transcend SSD 480GB + 1x SPCC SSD 240GB + 1x WDC 1TB
- Ethernet : 1x Intel I219-V7 + 1x AQC107
- Wifi : Intel AC 9560 (From Board Package)
- USB : Intel Chipset
- PCIe : 1x Gigabyte GC-Titan Ridge Thunderbolt 3 (JHL7540)
- Audio Codec : Realtek ALC1220A
- USB Wifi : TP-Link AC 1300
- PSU : PSU Coolermaster v1000
- Case : NZXT H700 White
- Mouse : Steelseries Rival 650
- Monitor Model and Size : 1x 5K Display LG UltraFine Display from Thunderbolt
- Monitor Resolution : 5K (5120 x 2880)
- Boot Mode : UEFI
- Clover Version : r5033
- OS Version : macOS Mojave 10.14.5 Build 18F132
Work????
- QE/CI of Sapphire Radeon VII
- Intel Quick Sync
- Restart, Sleep and Shutdown
- CPU Power Management
- Ethernet Intel I219-V7
- Ethernet AQC107
- Realtek ALC1220A
- Wifi of TP-Link AC 1300
- Display Port
- Thunderbolt Port from Titan Ridge for 5K Display
- All Port USB and Super Speed USB 3.1 Work including USB C
- PCIe Thunderbolt (Gigabyte GC-Titan Ridge)
- Dll
Not Work??
- Wifi Intel AC9560 (Intel Wifi Chipset is not supported by Hackintosh)
- Etc
Keep Hackintosh and Keep Hairfall !!!
